WIRING DIAGRAMS
104
1 - Remote control box
2 - Battery
3 - 12 V, 800 W (DC)
4 - Extension cord (optional)
5 - Fuse (15 A)
6 - Rectifier (optional)
7 - Extension cord, light (optional)
8 - Receptacle plug (optional)
9 - Lamp (12 V, 80 W) (AC)
10 - Tachometer (optional)
11 - Separate cord (yellow) (optional)
12 - Separate cord (white) (optional)
13 - Flywheel magneto
14 - Ignition coil
15 - Spark plug
16 - CD unit
17 - Stop switch (optional)
18 - Stop switch
19 - Remote control stop cord (optional)
20 - Remote control stop switch
