INSTALLATION
38
4.
Connecting remote control cable to the remote control
box: Remove the back panel by loosening two screws.
37528
a
a - Back panel
5. Thread the remote control cables through the terminal eyes at
a distance of more than 11 mm (0.43 in.). Securely lock the
terminal eyes with the nut lock.
11mm
a
b
37497
a - Terminal eyes
b - Nut lock
