4. PARTS DESCRIPTION
4 PARTS DESCRIPTION
The parts description for the Mambo Mini and
Mambo Standard are listed below. The numbers
refer to the diagram (right):
1. Controller
2. Armrest
3. Headrest
4. Seat back rest
5. Seat base
6. Back rest recline handle
7. Drive (rear) wheel
8. Castor (front) wheel
9. Foot rest
10. Shroud
1
2
3
7
8
9
12
4
5
2
6
11
10
The parts description for the Mambo Midwheel is
listed below. The numbers refer to the diagram (left):
1. Controller
2. Armrest
3. Headrest
4. Seat back rest
5. Seat base
6. Back rest recline handle
7. Drive (mid) wheel
8. Castor (rear) wheel
9. Anti-tip (front) wheel
10. Foot rest
11. Shroud
12. Seat rotation lever
