Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
19 20A** High beam relay
20 30A** Electric brake
21 30A** Front wiper motor
22 20A** Autolamp; Low beam
23 30A** Ignition switch
24 20A* Rear fog lamps (Export only)
25 – Not used
26 15A* Fuel pump
27 20A* Trailer tow lamps
28 20A* Horn relay
29 60A** PJB
30 20A** Rear wiper motor
31 — Not used
32 — Not used
33 30A** Auxiliary blower motor
34 30A** Power seats, Adjustable pedals
35 20A** Rear power point
36 40A** Blower motor
37 15A* A/C clutch relay/Transmission
38 15A* Coil on plug
39 15A* Injectors/Fuel pump relay
40 15A* PTEC power
41 15A* HEGO, VMV, CMS, PTEC
42 10A* Right low beam
43 10A* Left low beam
44 15A* Front foglamps
45 5A* Brake pressure switch
46 20A* High beams
47 — Horn relay
48 — Fuel pump relay
49 — High beam relay
Roadside emergencies
213
