Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
33 30A* Driver seat motors, Memory
module
34 30A* Ignition switch (to SJB)
35 — Not used
36 40A* Front A/C blower motor
37 30A** Front wiper, Front washer
38 5A** Heated Positive Crankcase
Ventilation (PCV) valve
39 — Not used
40 10A** TCM, EVMV, Canister vent, ESM,
Exhaust Gas Oxygen heaters, A/C
clutch
41 15A** PCM, Injectors, Ignition coils,
Mass Air Flow (MAF) sensor
42 — Not used
43 — Not used
44 — Not used
45 — Not used
46 — Not used
47 — Not used
48
1
⁄ 2 ISO relay Fog lamps
49 — Not used
50 — Not used
51
1
⁄ 2 ISO relay A/C clutch
52 — Not used
53
1
⁄ 2 ISO relay Fuel pump driver module, Fuel
pump
54 — Not used
55 Full ISO relay PCM relay, PDB fuses 40 and 41
56 Full ISO relay Starter motor solenoid
57 Full ISO relay Front A/C blower motor
2005 Montego (mgo)
Owners Guide (post-2002-fmt)
USA_English (fus)
Roadside Emergencies
190
