DIRECT FUEL INJECTION
90-855347R1 JANUARY 1999 Page 3B-9
Air Handler Components
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
– 1 AIR HANDLER
1 1 ADAPTOR PLATE KIT
2 1 GASKET
3 1 GASKET
4 6 REED BLOCK
5 12 SCREW (1/4-20 x .88) 100 11.5
6 1 OIL PUMP
7 1 GASKET
8 1 BRACKET
9 3 FITTING
10 3 FITTING
11 1 ELBOW
12 1 FITTING (STRAIGHT)
13 6 BUSHING
14 6 GROMMET
15 6 SCREW 140 12 16
16 6 WASHER
17 1 AIR PLENUM KIT
18 1 ELBOW
19
1 ELBOW (.236 O.D.)
19
1 ELBOW (.159 O.D.)
20 1 GASKET
21 1 TEMPERATURE SENSOR
22 3 SCREW Drive Tight
23 3 LOCKWASHER
24 12 SCREW (M4 x 16) Drive Tight
25 1 THROTTLE BODY KIT
26 1 O RING
27 4 SCREW 100 11.5
