CHARGING & STARTING SYSTEM
90-855347R1 JANUARY 1999 Page 2B-9
Flywheel/Alternator
TORQUE
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 ALTERNATOR
2 1 SCREW (M10 x 100) 480 40 54
3 1 SCREW (M10 x120) 275 23 31
4 3 WASHER
5 3 MOUNT
6 1 BRACKET
7 3 WASHER
8 1 BRACKET
9 2 NUT 275 23 31
10 1 SCREW (M10 x 55) 275 23 31
11 1 CABLE
12 1 PIN
13 1 BRACKET
14 3 SCREW (5/16-18 x 1 IN.) 185 15.5 21
15 1 SPRING
16 1 BELT TENSIONER
17 1 STUD (M10 x 85)
18 1 NUT 180 15 20
19 1 BUSHING
20 2 WASHER
21 1 PULLEY
22 1 SCREW (M10 x 35) 300 25 34
23 1 BELT
24 1 FLYWHEEL
25 1 NUT 125 169
26 1 WASHER
27 1 PLUG
