Merit Megatouch Gametime PM0503-10

Questions and Answers

T
Tina TuckerAug 6, 2025
How to fix ERROR READING DRIVE C on Merit Megatouch Gametime PM0503-10?
- D
  David RosalesAug 6, 2025
  The 'ERROR READING DRIVE C' message on your Merit Video Game is often related to the hard drive. You can perform a checksum test on the hard drive. To do this, turn off the game, press and hold the SETUP button while turning it back on. On the diagnostic page, select the option for DIP switch 8. This test takes about 10 minutes. A failure will cause the test to stop, and if the hard drive fails the test, the game will lock up with a 'CHECKSUM ERROR' message. In this case, the hard drive will need to be replaced. A passed test will display 'DRIVE CHECKSUM COMPLETE RESET ALL DIP SWITCHES TO REBOOT MACHINE.'
A
Angie MccarthyAug 14, 2025
How to troubleshoot no power on Merit Megatouch Gametime PM0503-10 Video Game?
- L
  Larry MartinAug 14, 2025
  If your Merit Video Game has no power, check the following: * Make sure the power cord is securely connected to a working electrical outlet. * Ensure that the power switch is in the 'on' position. * Verify that the power cord is properly connected to the game itself.
A
Ashley MontesAug 21, 2025
How to improve poor picture quality on Merit Video Game?
- M
  moorematthewAug 21, 2025
  To improve poor picture quality on your Merit Video Game, adjust the Brightness, Contrast, Horizontal, and Vertical controls using the monitor controls located on the Control Board.
D
Dana WoodsOct 29, 2025
What to do if Merit Megatouch Gametime PM0503-10 locks up or resets?
- S
  Sergio RobertsOct 29, 2025
  If your Merit Video Game locks up or resets, you can try a few things. First, clean the vents and fans to remove any dust or dirt that might be blocking airflow. Next, you can perform a checksum test on the hard drive. To do this, turn off the game, press and hold the SETUP button while turning it back on. On the diagnostic page, select the option for DIP switch 8. This test takes about 10 minutes. If the test fails, the hard drive may need replacing. Alternatively, you can clear the memory by turning off the game, pressing and holding the Setup and Calibrate buttons, and turning the game back on. Hold the buttons until 'TWO BUTTON CLEAR DETECTED RELEASE BUTTONS' appears on the screen, then release them. This will reset high scores, books, options, and the game and coin menus to their fact...

Summary

Important Safety Instructions

Electric Shock Hazard Warning

Alerts users to the presence of dangerous voltage and advises against opening the enclosure.

Site Preparation Guidelines

Setting Up Your Game

General Care and Maintenance

Monitor Adjustment Guide

Instructions for adjusting vertical/horizontal size, position, brightness, and contrast.

General Care and Maintenance (Continued)

Watchdog Timer Functionality

Explains the automatic reboot feature for resolving operational problems.

Main Menu Overview

Games Menu Functions

Details options for game setup, editing game lists, and selecting game options.

System Menu Functions

Diagnostics Menu Functions

Explains tests for video, I/O, touchscreen, system logs, checksum, and info.

TournaTime Menu Functions

Games Menu Details

Configuring Game Setup Options

System Menu Details

Diagnostics Menu Functions

Performing Video Test

Performing I;O Test

Touchscreen Calibration Procedure

Follows on-screen instructions to calibrate the touchscreen accuracy.

Performing Touchscreen Test

Performing Hard Drive Checksum Test

Checks the hard drive for corrupted files; may take up to 30 minutes.

TournaTime Menu Functions

Configuring LAN Connection

My Merit Account Features

Managing My Merit Account Options

Broadband Internet Setup

Broadband Internet Connection Guide

Guides on connecting the game to a broadband internet connection.

On-Screen Internet Configuration

Steps to configure network settings directly on the game's screen.

Broadband Internet Setup (Continued)

Automatic vs. Manual Internet Setup

Explains selecting automatic (dynamic IP) or manual (static IP) settings.

Automatic Internet Setup Configuration

Manual Internet Setup Configuration

Instructions for entering static IP address and gateway information.

Wireless Broadband Internet Setup

Wireless Router Setup and Game Connection

Instructions for installing router and connecting game via wireless.

Configuring Wireless Device Options

Details options like Auto Detect, Search for Networks, Secured, Unsecured, Ad-Hoc.

Custom Wireless Configuration

Merit Link Service

Merit Link for Purchases and Subscriptions

Accessing Merit Link to purchase games or subscribe to GTnet service.

Merit Link User Guide Reference

TournaTime Tournament Play

TournaTime Networking for Tournaments

TournaTime Player Registration

Merit Link User Guide

Merit Link Registration and GTnet Subscription

Steps for registering with Merit Link and subscribing to GTnet.

Merit Link Order Options

Merit Link User Guide (Continued)

Process of Purchasing Games

Steps to add games to cart, review, and complete purchase.

Redeeming Free Games via Code

DIP Switch Settings

Motherboard Configuration and Checksum Test

Configures CMOS settings and checks motherboard files for integrity.

Hardware Configuration and System Identification

GTnet Memory Clear

Complete Memory Clear

Watchdog Timer Function

Troubleshooting Guide for Gametime Games

Troubleshooting Power, Monitor, and Fan Issues

Addresses problems like no power, blank monitor, and non-operating cooling fans.

Troubleshooting Picture Quality and Game Lockups

Covers poor picture quality and games locking up or resetting during play.

Troubleshooting Screen Movement and Power Cycling

Addresses issues with no screen movement or needing power cycles to function.

Troubleshooting Drive Read Errors

Diagnoses 'ERROR READING DRIVE C' messages, potentially requiring drive replacement.

Troubleshooting Guide for GTnet

Troubleshooting GTnet Server Address and Information

Addresses issues with server IP, invalid information, and security keys.

Troubleshooting Serial Number and Connection Issues

Covers invalid serial numbers and connection interruptions due to data transfer.

Troubleshooting Server Errors and Availability

Deals with server errors, servers not found, and lack of response to requests.

Troubleshooting Server Name Lookup and Detection

Addresses server name lookup failures and inability to detect the TournaTime server.

Troubleshooting Wireless Installation

Troubleshooting Wireless Connection Issues

Ensures Wireless USB Adapter is configured with correct SSID and WEP encryption.

Troubleshooting Sporadic Wireless Connections

Addresses intermittent connection problems, suggests checking Link Quality and interference.

Merit Video Machine Limited Warranty

Merit Video Machine Warranty Coverage

Covers electrical components and PCBs for one year; touchscreen for 3 years.

Merit Video Machine Warranty Exclusions

Merit Repair and Replacement Policy

Merit Software License Agreement

Software Ownership and Intellectual Property

States that software and documentation are owned by Licensor and protected by law.

Software Use and Transfer Restrictions

Details limitations on copying, media usage, and permanent transfer of the license.

Software Limited Warranty

Merit Software License Agreement (Continued)

Software License Grant

Grants a limited, non-exclusive license to use one copy of the software per machine.

Software Disclaimers

Software Liability Limitations
