Merlin Gerin itm 4c 6e User Manual

11
Schneider Electric
Centre Merlin Gerin
F-38050 Grenoble cedex 9
tél. : 04 76 57 60 60
12 10
11
51112370BA
As standards, equipment, characteristics and dimensions develop from time to time, always ask for confirmation of
the information given in this publication.
This product must be installed, connected and used in compliance with current installation standards and regulations.
Ctrl Count. Cond. ON override RESET Connected item
E1 vvv v v.................................................
E2 vvv v v.................................................
Function programmed: E3 vvv v v.................................................
v Weekl. prog. v Close delay v Flash device E4 vvv v v.................................................
v Yearl. prog. v Open delay v Time count. E5 vvv v v.................................................
v Impuls. prog. v Timer v Impul. meter E6 vvv v v.................................................
Time ranges 1 2 3 4 5
Time Date Time Date Time Date Time Date Time Date
ON
OFF
Days
MTWTFSS MTWTFSS MTWTFSS MTWTFSS MTWTFSS
vvvvvvv vvvvvvv vvvvvvv vvvvvvv vvvvvvv
Circuit controlled: .................................................
Function configuration (delay duration, impulse, timer, counting threshold...):....................................................................................................................
.................................................................................................................................................................................................................................................
Channel 3
DUPLICATE
PROGRAMME
PRODUCT
> CARTRIDGE
(1)
DUPLICATE
PROGRAMME
CARTRIDGE
> PRODUCT
(2)
b The cartridge can be used on all ITMs.
b It lets you duplicate the program of your ITM (back-up
copy) or incorporate this program into another ITM.
b You can duplicate the ITM's program on the cartridge (1)
or the cartridge on the ITM (2).
b In the "PROGRAM" mode, select "DUPLICATE".
Use the memory cartridge (cat. no. 15280 optional)
Characteristics
b Consumption: max. 45 VA
b Memory:
v 45 time ranges in weekly programming,
v 15 time ranges in yearly programming,
v 20 ranges in impulse programming.
b
Minimum time between 2 programmed switching
operations:
b 1 min
b In event of mains power cut:
v the display disappears,
v clock (date, time) is backed up by lithium battery:
- lifetime: 10 years,
- Back-up time: 5 years,
v program saved by EEPROM
v the module cannot be programmed until it is
re-energised.
b
Operating temperature: -5°C … +50°C
b (preferably install in the least hot part of the enclosure).
b Degree of protection: IP 40 in the electrical switchboard
b Connection terminals:
v max. capacity: 6 mm
2
,
v recommended screwdriver: posidriv 1 or flat 0.8x4 mm,
b Standard cartridge: EEPROM
b
Dimensions (9mm pitch): 10 pitch
b Weight: 290g
Discover the summer/winter time changeover function
b This function lets you select your summer/winter time automatic changeover.
b By default, your ITM uses European parameters:
v Europe:
- summer (last weekend in March +1 hour)
- winter (last weekend in October - 1 hour)
b For other parameters specific to your geographic zone, enter the month and the
corresponding week.
b In the "PROGRAM" mode, choose "SUM/WIN TIM" then "EUROPE" or "OTHER",
to be defined.
b In the manual mode, you can directly adjust the product to make the summer/winter time
changeover.
"
Configuration Sheet
Ctrl Count. Cond. ON override RESET Connected item
E1 vvv v v.................................................
E2 vvv v v.................................................
Function programmed: E3 vvv v v.................................................
v Weekl. prog. v Close delay v Flash device E4 vvv v v.................................................
v Yearl. prog. v Open delay v Time count. E5 vvv v v.................................................
v Impuls. prog. v Timer v Impul. meter E6 vvv v v.................................................
Time ranges 1 2 3 4 5
Time Date Time Date Time Date Time Date Time Date
ON
OFF
Days
MTWTFSS MTWTFSS MTWTFSS MTWTFSS MTWTFSS
vvvvvvv vvvvvvv vvvvvvv vvvvvvv vvvvvvv
Circuit controlled: .................................................
Function configuration (delay duration, impulse, timer, counting threshold...):...................................................................................................................
.................................................................................................................................................................................................................................................
Channel 4
