MERLYN 8 Series User Manual

100％ Level
!
TRAY MUST BE LEVEL IN ALL DIRECTIONS!
Ensure the shower tray is level in all directions and is
properly sealed to the wall. The wall must be tiled down to
the top edge of the tray. Do not angle out bottom tile.
TRAY MUST BE SEALED FULLY AROUND WHERE
THE TRAY MEETS THE WALL.
PROCEDURE
100％ level
1
2
1
B
C
D
E
INSTALLATION GUIDE
4
LH RH
Note:Determine the handing, note that the
wall profile is only fitted to the hinged side.
A
Determine distance from edge
of tray to front of profile.
Mi
n 1
0m
m
NOTE: If fitting as corner door please refer to the adjustment table on page 1.
We do not recommend fitting the product on a shower trays when used as a showerwall
or corner door.

MERLYN 8 Series Specifications

General

Magnetic Seals	Yes
Glass Thickness	8mm
Finish	Brushed Nickel
Reversible	Yes
Glass Finish	Clear
Frame Finish	Brushed Nickel
Material	Aluminum
Installation Type	Wall Mount
Height	1950mm
