Mesa/Boogie Nomad Amplifier 45

PAGE 36
1
2
5
4
4 Ohm Cabinet
3
8 OHM 4 OHM 4 OHM
Partial back view of
some Mesa amp
8 Ohm Cabinet
SAFE MISMATCH
WIRING SCHEMES...Amplifier to Speaker Cabinets
4 OHM 8 OHM 16 OHM
Partial back view of amplifier
16 Ohm Cabinet
4 OHM 8 OHM 16 OHM
Partial back view of amplifier
16 Ohm Cabinet
SAFE MISMATCH
8 OHM 4 OHM 4 OHM
Partial back view of amplifier
8 OHM 4 OHM 4 OHM
Partial back view of amplifier
8 Ohm Cabinet
MISMATCH
MATCH CORRECT
