Page 2 of 47
Quick Installation Guide
For quick installation of the FTC320 we recommend reading the following chapters of this manual:
• Chapter 1 "Operator Safety": Important warnings, safety instructions and intended use.
• Chapter 3 "Assembly of the Instrument": Mounting, pneumatic and electric connection. Also see
Chapter 10 "Appendix: Dimensional Drawing"
• Section 7.1 "Calibration": Recommended calibration intervals, the calibration process and rec-
ommended test of functionality after bringing into service.
File name:
FTC320Ex Operating Manual_1.09KD201009MPO3V04.pdf
