REPLACEMENT PARTS LIST
ACCESSORIES
7.
On a typical forced hot water system, connect return to inlet side of circulator and supply upstream of re-
motely operated valve. Unit may also be connected to mains of an existing loop system of sufcient capacity.
Operation will be inuenced by the system circulator and associated controls.
Installation of a pump and line voltage thermostat will provide the unit with its own “zone” control.
With the addition of a circulator pump, hot water storage tanks may be used (where codes permit) as a supply
source if proper precautions are taken, and if realitively low water temperatures can be tolerated. Be sure tank
can supply additional load of the Kickspace heater and 120°F water. Supply is taken from top of tank, and
returns at the cold water inlet with a check valve. Do not return to bottom drain tapping.
Operation from steam boiler water is entirely possible as long as supply and return connection is installed be-
low level of water line on a steam boiler. This installation requires an optional circulator pump and line voltage
thermostat. Check local building codes.
Model
Description Part No. 42 84 120
Quick-Connect Hose Kit HK-10 x x x
Model
Description Part No. 42 84 120
Motor-Fan Assembly
BMKR02020-001 x
BMKR02020-002 x
BMKR02020-003 x
Standard Aquastat Assembly (120° – 105°F)
BMKR02024-001 x x
BMKR02024-002 x
Low Temp. Aquastat Assembly (110° – 95°F)
BMKR0204-L01 x x
BMKR0204-L02 x
Heating Element
BMKR02017-001 x
BMKR02017-002 x
J37R52064 x
2 Speed Fan Switch J11R02029-001 x x x
Outlet Grille w/ screws (Model K only) (Black)
BMKR08778-B42 x
BMKR08778-B84 x
BMKR08778-B12 x
Louvered Front Panel (Model W only)
BMWR02172-001 x
BMWR02172-002 x x
Louvered Front Panel (Model F only)
BMFR02165-001 x
BMFR02165-002 x x
Louvered Front Panel (Model FK only)
FKR02437-001 x
FKR02437-002 x x
