MSM43J(T)1702020
1 Connect to IGNITION (+15) via the supplied fuse and holder.
ENSURE the ignition remains live whilst cranking
2 Connect to Permanent POSITIVE (+30) via the supplied fuse and holder.
3 Connect to GROUND (-31)
3B Connect to a different GROUND (-31) point
KEY See Diagram on next page
3A
LED Connect to RED/BLACK of LED
3C Connect to BLACK of LED
RELAY 1
4 Connect to SUPPLY side of cut (fuel pump, ignition relay etc)
5 Connect to LOAD side of cut (fuel pump, ignition relay etc)
6 Not Used
NOTE: Do not cut a permanent live circuit; cutting a negative control circuit is possible if required.
RELAY 2
7 Connect to SUPPLY side of STARTER cut
8 Connect to LOAD side of STARTER cut
10 Not Used
ANT The majority of the wire can be taped into the wiring loom; ensure the last 24cm is free.
To Next Page
