META 82456 - Rack Dimensions and Tolerances; Rack Proportions and Measurements

A
A
min. B 15
min. 150mm
11
Das Lagersystem
L
H
H / 350
H / 350
H / 350
H
L
X
Æ 10
Æ 10
100
2,0 mm
H : T ≥ 5 : 1
!
DIN 18202
L m X mm
< 1,0 max. 4
> 1,0 - 4,0 max. 10
> 4,0 - 10,0 max. 12
> 10,0 - 15,0 max. 15
H
T
07 Meta - Mini - Rack 2011-11_82456++Wortlos++:Meta - Mini - Rack 09.11.2011 14:14 Seite 11
