5
With the appropriate accessories this rotary
hammer drill is suitable for impact drilling with
impact masonry bits and chiselling into concrete,
stone and other such materials, with impact core
drill bits (KHE 28) into masonry and similar
materials as well as for non-impact drilling into
metal, wood, etc. and for driving screws.
The user bears sole responsibility for any damage
caused by inappropriate use.
Generally accepted accident prevention
regulations and the enclosed safety information
must be observed.
Please write the type number, shown on your
tool’s rating label, into the field provided for this
purpose in the spare parts list. You need this
number to order spare parts.
Before using this power tool, completely read and
understand the enclosed safety information (red
booklet) and the instructions. Keep all enclosed
documentation for future reference, and pass on
your power tool only together with this
documentation.
For your own protection and
the protection of your power
tool, observe the passages
marked by this symbol!
Wear sturdy work shoes!
Take care to avoid gas, electricity, and water
supplies!
2 Specified Conditions of Use
3 Identification Number
4 General Safety Information
5 Special Safety Information
9.8 Contact mode
10 Tips and Tricks
11 Maintenance
12 Trouble Shooting
13 Accessories
14 Repairs
15 Protection of the Environment
16 Technical Specifications
We hereby declare at our sole responsibility that
this product conforms to the standards and
normative documents mentioned on page 2.
1 Declaration of Conformity
9.6 Tool change with SDS chuck
9.7 Tool change with Futuro Plus keyless
chuck (not for BH 20, BHE 20)
9.5 Selection of direction of rotation
1 Declaration of Conformity
2 Specified Conditions of Use
3 Identification Number
4 General Safety Information
5 Special Safety Information
6 Overview
7 Special Product Features
8 Start of Operation
8.1 Side handle installation
9Use
9.1 Depth stop setting
9.2 Switching on/off
9.3 Speed preselection (KHE 24 Contact)
9.4 Operating mode selection
Contents
Operating Instructions
Dear Customer,
Thank you for the trust you have placed in us by buying a Metabo power tool. Each Metabo power tool
is carefully tested and subject to strict quality controls by Metabo’s quality assurance. Nevertheless, the
service life of a power tool depends to a great extent on you. Please observe the information contained
in these instructions and the enclosed documentation. The more carefully you treat your Metabo power
tool, the longer it will provide dependable service.
(KHE 26 Contact)
(KHE 26 Contact)
BHE 22, BHE 24,
KHE 24 SP)
1 BHE22 ENG_0706 16.09.2008 14:08 Uhr Seite 5

Metabo BHE 22 Specifications

General

Chuck type	SDS Plus
Adjustable speed	Yes
Impact rate	4600 bpm
Torque (max)	11 N⋅m
Drilling diameter in wood (max)	30 mm
Drilling diameter in steel (max)	13 mm
Drilling diameter in concrete (max)	22 mm
Output power	370 W
Power source	AC

Weight and Dimensions

Weight	2400 g
