Metabo MAG 32 Original Instruction

ENGLISH en
15
Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating instruc-
tions.
See page 4.
A Core drill with 19 mm Weldon shank, HSS/HM
B Centring pin, short,
HSS: for 30 mm cutting depth
HM: for core drill bit diameter 14-17 mm
C Centring pin, long,
HSS: for 55 mm cutting depth
HM:0 for core drill bit diameter 18-100 mm
D Morse taper for chuck with female taper
E Key-type chuck with female taper
F Metal drill bit
G Quick replacement system MK2 on Weldon,
19 mm
H Industrial holder MK2 on Weldon, 19 mm
I Securing belt with ratchet
J Universal cutting spray
K Weldon adapter, 19 mm, on thread ½“ x 20 UNF
L Geared chuck with thread ½“ x 20 UNF
M Adapter Weldon, 19 mm, on Fein Quick In
For a complete range of accessories, see
www.metabo.com or the main catalogue.
Have your power tool repaired by a qualified electri-
cian. This power tool complies with the applicable
safety regulations. Repairs must only be carried out
by qualified electricians and using original spare
parts; otherwise the user faces a risk of accidents.
Any Metabo power tool in need of repair can be sent
to one of the addresses listed in the spare parts list.
Please attach a description of the fault to the power
tool.
Metabo's packaging can be 100% recycled.
Scrap power tools and accessories contain large
amounts of valuable resources and plastics that can
be recycled.
These instructions are printed on chlorine-free
bleached paper.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline 2002/
96/EC on used electronic and electric equipment
and its implementation in national legal systems,
used power tools must be collected separately and
handed in for environmentally compatible recycling.
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
T=Tool attachment
M=Max. torque
D
max, K
=Max. diameter (core drill bit)
D
max, S
=Max. diameter (spiral drill bit)
D
max, T
=max. diameter (tap)
P
1
=Nominal power input
P
2
=Power output
n
1
=Speeds at rated load
H
max
=Max. stroke
H
u
=Height (incl. motor) with slide plate in
bottom position
H
o
=Height (incl. motor) with slide plate in top
position
A =Dimensions of magnetic flux
m =Weight without mains cable
A-effective perceived sound levels:
L
pA
=Sound pressure level
L
WA
=Acoustic power level
K
pA
, K
WA
= Uncertainty (noise level)
During operation the noise level can exceed
80 dB(A).
Wear ear protectors!
Measured values determined in conformity with
EN 61029.
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
10. Accessories
11. Repairs
12. Environmental Protection
13. Technical specifications

Metabo MAG 32 Specifications

General

Chuck type	-
Adjustable speed	Yes
Torque (max)	50 N⋅m
Idle speed (max)	700 RPM
Sound power level	98 dB
Sound pressure level	85 dB
Sound level uncertainty	3 dB
Drilling diameter in steel (max)	- mm
Vibration level (metal drilling)	2.5 m/s²
Input power	1000 W
Cable length	5 m
Output power	520 W
Power source	AC
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Product color	Black, Green, Grey
Uncertainty K	1.5 m/s²

Weight and Dimensions

Weight	11900 g
