4
A
D d
115 mm 12 mm 6.24840
123 mm 12 mm 6.23287
147 mm 12 mm 6.23288
173 mm 12 mm 6.23289
D
d
D
D d
130 mm 5 mm 6.24964
155 mm 5 mm 6.24965
C
D d
80 mm 20 mm 6.24092
130 mm 25 mm 6.24967
130 mm 50 mm 6.24926
160 mm 25 mm 6.24968
160 mm 50 mm 6.24927
B
D d
80 mm 25 mm 6.24912
130 mm 25 mm 6.24913
160 mm 25 mm 6.24915
160 mm 50 mm 6.24916
E
D
85 mm 6.24063
130 mm 6.31223
160 mm 6.31217
F
D
80 mm 6.24061
125 mm 6.31216
150 mm 6.24037
G
D
175 mm 6.24261
