Metra Electronics 70-1727 - Technical Wiring and Location Details; Factory Amplifier Location; Wire Colors for Bypass Harness

REV
.
04/01/09
INST70-1727
Wire Colors for Bypass Harness:
Yellow / Blue Left Front Tweeter (+)
Yellow / Black Left Front Tweeter (-)
The rest of the wires are standard Metra / EIA
color code that can be found on the back of
this package.
Center console, in front of the shifter.
Yellow / Red Right Front Tweeter (+)
Yellow / Orange Right Front Tweeter (-)
Green / White Subwoofer (+)
White / Red Subwoofer (-)
F Y
ACTOR
AMP LOCA
TION:
2 Door EX and SI:
4 Door SI:
Under drivers seat.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
