Kit Assembly 95-7879
3
Kit Preparation
1. Locate the factory wiring harness
in the dash. Metra recommends
using the proper mating adapter
from Metra or AXXESS. Re-connect
the negative battery terminal and
test the unit for proper operation.
2. Slide the double DIN radio into the
brackets and secure the double
DIN radio to the assembly using
the screws supplied with the radio.
(Figure B)
3. Secure the radio housing brackets
to the radio housing with four #8
x 3/8” Phillips screws provided.
(Figure C)
4. Reassemble dash in reverse order
of disassembly using the supplied
#8 screw in place of the factory
screw removed in step one,
(Figure B) of the dash disassembly.
Double DIN radio provision
(Figure A)
Hazard switch
Red factory clip
White
plastic
clips
White
plastic
clips
Air bag light
Metal clip
(Figure A)
(Figure B)
