Metra Electronics 99-6515B - Kit Assembly; DIN Head Unit Provision

DIN head unit provision
Kit Assembly 99-6515
(Figure A)
(Figure B)
1. Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (Figure A)
2. Slide the aftermarket head unit into
the cage and secure. (Figure B)
3. Locate the factory wiring harness
and antenna plug in the dash. Metra
recommends using the proper mating
adapters from Metra and/or AXXESS.
4. Reassemble dash in reverse order
of disassembly.
