Metra Electronics 99-7339B - Dash Disassembly; Hyundai Genesis Coupe 2010

99-7339 DASH DISASSEMBLY
HYUNDAI GENESIS COUPE 2010
A
B
C
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the shifter trim
panel. ( Figure A)
2
Unclip and remove the radio/climate
control trim panel. (Figure B)
3
Unclip and remove the display trim
panel above radio.
(Figure C)
4
Remove (4) Phillips screws securing
the radio.
5
Remove (4) Phillips screws securing
the climate control to the factory trim
panel.
6
