9
DDIN head unit provision
(Figure D)
4. Mount the Unified Amp Meter to the
radio/bracket assembly using (2)
supplied 3/8” Phillips screws.
(Figure D)
5. Mount the whole DDIN radio/meter
assembly to the radio trim panel using
(4) supplied 3/8” Phillips screws.
(Figure E)
6. Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from Metra
or AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
7. Reassemble dash in reverse order of
disassembly.
Kit Assembly 99-7612
(Figure E)
