Metra Electronics 99-9600 - Fairing Disassembly; FLH;Batwing Models Disassembly

99-9600
FLH/Batwing models:
1. Coverthefrontfender.
2. Remove(2)T-27Torxboltsfrominner
fairing(undermirrors)(FigureA,step2)
3. Remove(2)T-27Torxboltsfromouter
edgesofinnerfairingneartheforktubes
(facingforward)(FigureA,step3)
4. Remove(3)T-27Torxboltsfrombottom
edgeofwindshield.(FigureA,step4)
NOTE: Windshield and fairing
will be loose once these screws
are removed. Use extreme
caution not to damage fairing or
windshield.
5. Removewindshieldtakingcautionthat
theouterfairingisloose.

Fairing Disassembly
(Figure A)
Step 2 Step 2
Step 3
Step 4
