Display Combo/RFID/Keypad Technical Manual
 Connections
 Display Combo
Connect the communication cable (10 pole flat cable) from the Locker Controller to the connector
marked .
 Display RFID
Connect the communication cable (10 pole flat cable) from the Locker Controller to the connector
marked .
 Display Keypad
Connect the communication cable (10 pole flat cable) from the Locker Controller to the connector
marked .
