METREL MD 9020 User Manual

MD 9020 Electrical & Electronic DMM Specification
18
DC Current
RANGE Accuracy Burden Voltage
400.0A
2.0% + 5d
0.15mV/A
4000A
1.2% + 3d
0.15mV/A
40.00mA 2.0% + 5d 3.3mV/mA
400.0mA 1.2% + 3d 3.3mV/mA
4.000A 2.0% + 5d 0.03V/A
10.00A* 1.2% + 3d 0.03V/A
*10A continuous, 20A for 30 second max with 5 minutes cool down interval
AC Current
RANGE Accuracy
1)
Burden Voltage
50Hz -- 500Hz
400.0A
2.0% + 6d
0.15mV/A
4000A
1.5% + 4d
0.15mV/A
40.00mA 2.0% + 6d 3.3mV/mA
400.0mA 1.7% + 4d 3.3mV/mA
4.000A 2.0% + 6d 0.03V/A
10.00A* 1.8% + 4d 0.03V/A
*10A continuous, 20A for 30 second max with 5 minutes cool down interval
Diode Tester
Open Circuit Voltage Test Current (Typical)
< 1.6 VDC 0.25mA
Type-K Temperature (MD 9020)
RANGE Accuracy*
-20
O
C TO 300
O
C 2% + 3
O
C
-4
O
F TO 572
O
F 2% + 6
O
F
*Type-K thermocouple range & accuracy not included
Audible Continuity Tester
Audible threshold : between 10 and 120
Ohms
RANGE Accuracy
400.0
0.8% + 6d
4.000k, 40.00k,
400.0k
0.6% + 4d
4.000M
1.0% + 4d
40.00M
2.0% + 4d
Open Circuit Voltage : 0.4VDC typical
Capacitance
RANGE* Accuracy**
500.0nF, 5.000F,
50.00F, 500.0F,
3000F
3.5%*** + 6d
*Additional 50.00nF range accuracy is not specified
**Accuracies with film capacitor or better

METREL MD 9020 Specifications

General

Brand	METREL
Model	MD 9020
Category	Multimeter
Language	English
