MD 9240 True RMS Power Clamp Meter Specification
18
Dimension: L224mm X W78mm X H40mm
Weight: 224 gm approx
Jaw opening & Conductor diameter : 45mm max
Special features:
 Backlight display,
 AutoVA
TM
(Auto Selection on ACV, DCV or ACA functions);
 Power measurement of selectable W, VAR & VA with dual-display Total Power Factor features;
 PEAK-rms HOLD
Accessories :
 Test leads (pair),
 batteries installed,
 user's manual,
 soft carrying pouch, AMD 9023 banana plug type-K thermocouple
Optional accessories:
 AMD9235 PC interface kit (including optical adapter back, cable & software CD),
 AMD9024 banana plug to type-K socket plug adaptor
Electrical Specifications
Accuracy is ±(% reading digits + number of digits) or otherwise specified, at 23
o
C ±5
o
C & less than 75%
R.H.
True RMS ACV & ACA clamp-on accuracies are specified from 0% to 100% of range or otherwise
specified. Maximum Crest Factor are as specified below, and with frequency spectrums, besides
fundamentals, fall within the meter specified AC bandwidth for non-sinusoidal waveforms. Fundamentals
are specified at 50Hz and 60Hz.
AC Voltage
RANGE
Accuracy
50Hz / 60Hz
600.0V
0.5% + 5d
45Hz ~ 500Hz
600.0V
1.5% + 5d
500Hz ~ 3.1kHz
600.0V
2.5% + 5d
CMRR : >60dB @ DC to 60Hz, Rs=1k
Input Impedance: 2M, 30pF nominal
Crest Factor:
< 2 : 1 at full scale & < 4 : 1 at half scale
ACV AutoVA
TM
Threshold: 30VAC (40Hz ~ 500Hz only) nominal
DC Voltage
RANGE
Accuracy
600.0V
0.5% + 5d
NMRR : >50dB @ 50/60Hz
CMRR : >120dB @ DC, 50/60Hz, Rs=1k
Input Impedance: 2M, 30pF nominal
DCV AutoVA
TM
Threshold: 2.4VDC nominal
