Metrix MX2033 User Manual

Doc# 100576 • REV C (Sept 2017) Page 12 of 42
3.3.2 APPLY POWER
You must apply 24 Vdc power to the DPS while conguring as shown in Figure 9. Note that
you can use either a negave or posive power supply (Refer to the DPS datasheet for volt-
age and current requirements.) Powering is the same for either the MX2033 or the MX2034.
The MX2034 does not require load resistors when conguring.

3.4 LAUNCHING THE DPS CONFIGURATION SOFTWARE
Launch the DPS Conguraon Soware by double-clicking the icon:
NOTE: Install the soware before connecng and pow-
ering the DPS to ensure the computer nds the correct
USB driver
Common
-24V
Common
+24V
