143
NL
ELECTRICAL DIAGRAM (GSC2100)
GEEL/GROEN
GEEL/GROEN
Schakelaar
Schakelaar
RELAIS
RELAIS
COMPRESSOR
PTC-STARTER
LEDLAMP LEDVOEDING
LEDLAMP LEDVOEDING
LEDLAMP
SENSOR
TEMPERATUURDISPLAY
VENTILATORMOTOR VERDAMPER
VENTILATORMOTOREN
CONDENSOR
LEDVOEDING
OVERBELAST-
INGSBESCHERM-
ING
ELEKTRISCH SCHEMA (GSC2100B-NC)
GEEL/GROEN
GEEL/GROEN
Schakelaar
SENSOR
RELAIS
RELAIS
COMPRESSOR
LEDVOEDING
TEMPERATUURDISPLAY
VENTILATORMOTOR
VERDAMPER
VENTILATORMOTOREN
CONDENSOR
OVERBELASTINGS-
BESCHERMING
PTC-STA
RTER
