7
Two Horizontally Arrayed PSW-6s @ 60 HZ.
Two Horizontally Arrayed PSW-6s @ 100 HZ.
Two Horizontally Arrayed PSW-6s @ 125 HZ.
Creating Large Horizontal Arrays
When creating a horizontal arch of more than two cabi-
nets additional electronics (beyond the standard LD-
1A) are required to help steer the system. Otherwise
there will be a significant decrease in the front to back
SPL ratio and excessive narrowing of the front polar
pattern at higher frequencies. For further information
on creating a large horizontal array contact Meyer
Sound Technical Support.
Set the Master, Mid-High and Sub gains on the LD-1A
