1. Moldboard
Steel sheet is bump and corrosion resistant. Built to last.
2. Cutting Edge
Replaceable high carbon steel provides extra long operating life;
should be 1/2” above ground in plowing position. (Can be higher
when used on gravel driveways.)
3. Runners
Adjustable and replaceable runners hold cutting edge at proper
height.
4. Trip Springs
Allow moldboard to trip forward and ride over obstructions, this
protects the snow plow, vehicle, and operator.
5. Pivot Bar
High quality steel - positions moldboard straight across, or angle
right or left.
6. Pivot Pin
Pin that attaches the pivot bar to the A-Frame.
7. A-Frame
Designed to attach the snow plow to the vehicle, to pivot moldboard
for angle plowing, and to hold plow at proper distance in front of
vehicle.
8. Power Angling Cylinders (1-1/2” x 10”)
Hydraulically positions the moldboard straight, or to right or left.
9. Clevis Frame
Allows snow plow assembly to be attached or detached from vehicle
in minutes.
10. Lift Frame
Allows for fast, complete removal of front end hardware, snow plow,
lights and hydraulic unit in one complete module.
11. Attaching Pins
Pull 1 handle to remove complete assembly.
12. Lift Arm
Chain locks in position to lift snow plow.
WARNING: LIFT ARM EXTENDS BEYOND BUMPER OF VEHICLE.
TO MINIMIZE DAMAGE FROM A FRONT END COLLISION, LIFT
ARM SHOULD BE REMOVED FROM VEHICLE WHEN SNOW
PLOW IS REMOVED.
13. Meyer Nite Saber
®
Snow Plow Lights
Complies with the Federal Motor Vehicle Safety Standards.
14. Electric Hydraulic Power Unit (E-58H)
Operates snow plow hydraulically- raises, lowers, angles, holds and
floats moldboard in plowing position.
15. Sno-Flo® Powder Coat
Baked on finish that looks like enamel, provides an extremely hard,
low friction surface that outlasts ordinary paint by a large margin.
Applied to all steel moldboards and mountings/frames.
16. Jackstand
Positions Moldboard and Lift Frame for easy attaching and
detaching.
™
