INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
STANDARD PV MODEL
ITEM PART NUMBER DESCRIPTION QTY
31 64066 ENGINE, 10.5 HP B &S W / VR 1
63171 ENGINE, HONDA W/DECALS
30 62187 NUT, 1/4-20 SER FLANGE 5
62690 NUT, 1/4-20 SER FLANGE ss
29 20003 BOLT, 1/4-20 X 3/4 HH 5
62189 BOLT, 1/4-20 X 3/4 HH ss
28 61167 RETAINER, CLUTCH 1
64399 RETAINER, CLUTCH s3
27 61168 COVER, CLUTCH 1
26 62763 BOLT, 5/16-18 X 3/4 HH 1
62752 BOLT, 5/16-18 X 3/4 HH ss
25 64401 A, WIRELESS REMOTE PV 1
24 61201 KEY, WOODRUFF 1/4 X 7/8 1
23 64086 CABLE, SPREADER CONTROL 1
22 61162 V-BELT, BX-48 1
21 SEE PARTS TABLE FORM, FLOOR PV 1
20 SEE PARTS TABLE CHAINSHIELD, PV 2
19 63305 BOLT, 5/16-18 X 3/4 CA 14
62640 BOLT, 5/16-18 X 3/4 CA ss
18 63304 NUT, 5/16-18 SER FLANGE 10
62641 NUT, 5/16-18 SER FLANGE ss
17 SEE PARTS TABLE WELD, DRAG CHAIN 1
16 62611 NUT, 3/8-16 SER FLANGE 9
62743 NUT, 3/8-16 SER FLANGE ss
15 20066 BOLT, 3/8-16 X 1 1/4 HH 6
62695 BOLT, 3/8-16 X 1 1/4 HH ss
14 63409 FLATWASHER, 3/8”SS 2
13 20305 LOCKNUT, 3/8-16 NYLON 3
63348 LOCKNUT, 3/8-16 NYLON ss
12 63264 FORMING, GUARD, CONVEYOR, PV 1
11 20329 LOCKWASHER, 1/2” MED SPLIT 4
62270 LOCKWASHER, 1/2” MED SPLIT ss
10 62617 BOLT, 1/2-13 X 3/4 4
62750 BOLT, 1/2-13 X 3/4 ss
9 63117 SUB-ASSEMBLY GEARBOX 1
8 62408 NUT, 1/2-13 HEX JAM 4
62336 NUT, 1/2-13 HEX JAM ss
7 62304 WELD, TAKE UP BOLT 2
6 64063 ROLLER, POLY 2
5 64062 SHAFT, IDLER 1
4 62641 NUT, 5/16-18 SER FLANGE SS 13
3 62628 LOCKNUT, 5/16-18 NYLON 3
63301 LOCKNUT, 5/16-18 NYLON ss
2 62007 DECAL, CAUTION 1
1 SEE PARTS TABLE WELD, PV 50” HOPPER 1
