INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
Item Component Description Qty
ELECTRIC PV MODEL
2 63410 Sub-Y, Gearbox 1
1 64454 Weld, Pv358 50” Hop 16g S2 Dm 1
3 64455 Bolt, 3/8-16 X 1-1/4 Ca Ss 1
4 63264 Form, Guard, Conveyor, Pv 1
5 64015 Motor, 12v 1650rpm 60a 1/2 Hp 1
6 62129 Weld, Drag Chain, 8 Ft 1
7 62750 Bolt, 1/2-13 X 3/4 Tap Hh Ss 4
8 62772 Lockwasher, 1/2”Med Split Ss 4
9 64456 Chain, Roller #40-94 Pitch W/C 1
10 62695 Bolt, 3/8-16 X 1-1/4 Hh Ss 5
11 63206 Lockwasher, 3/8” Med Split Ss 4
12 62743 Nut, 3/8-16 Ser Flange Ss 22
13 64457 Weld, Adapter 10g S2 1
14 64458 P, Control Vbel Electric Dual 1
15 63310 Nut, 5/16-18 Ser Flange Ss 22
16 61169 Knob, Hand 1
17 64459 Weld, Feedgate 10g S2 1
18 62697 Bolt, 3/8-16 X 1 Hh Ss 17
21 62336 Nut, 1/2-13 Hj Ss 4
19 22230 Flatwasher, 3/8” U.S.S. Ss 5
20 62304 Weld, Take Up 2
22 64460 Chainshield, Pv 8’ 16g S2 2
23 63881 Skid, Pv, 8 Ft 1
24 62657 Bolt, 3/8-16 X 4 Ca 4
25 64461 Form, Handle Feedgate 10g S2 1
26 63348 Locknut, 3/8-16 Nl Ss 2
27 64462 Bar, Pivot 10g S2 1
28 61174 Pin, Connector W/Cotter Pin 2
29 64463 Weld, Motor Cover 16g S2 1
30 64063 Roller, Poly 2
32 62009 Decal, Danger (Conveyor) 3
33 63333 Sprocket, 40b60-1” Bore 1
34 64464 Sprocket, 40b-11 5/8” Bore 1
31 62008 Decal, Serial No. 1
64448 P, Pv358 50 16g S2 Elec Dm
