PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
43
PARTS LIST FOR EXTENDED SPINNER ASSEMBLY
INTERMEDIATE - STANDARD (NEW)
ITEM PART. NO. QTY. DESCRIPTION
62929 00002-296-13 1 Standard (Steel) W/Poly Disc.
62930 00002-296-14 1 Standard (304SS) Spinner Assy.
1 62931 00119-091-01 1 • Weld, Spinner Frame (Carbon Steel)
62932 00119-091-02 1 • Weld, Spinner Frame (304 Stainless Steel)
2 62933 00119-083-00 1 • Shaft, Spinner
3 61180 00104-849-00 1 • Weld, Spinner Disc
62146 04622-033-00 1 • Disc, Poly Spinner
4 62356 04080-079-00 2 • Bearing
4b 61164 04080-011-00 2 • Bearing 1” (Old Style Hopper)
N/S 61187 00104-956-00 2 • Bearing Bracket, Weldment (Old Style)
5 61181 00104-811-00 1 • Weld, L. H. Baffle (Carbon Steel)
62273 00104-811-01 1 • Weld, L. H. Baffle (304 Stainless Steel)
6 61182 00104-810-00 1 • Weld, R. H. Baffle (Carbon Steel)
62272 00104-810-01 1 • Weld, R. H. Baffle (304 Stainless Steel)
7 61183 00104-835-00 1 • Weld, Rear Baffle (Carbon Steel)
62275 00104-835-01 1 • Weld, Rear Baffle (304 Stainless Steel)
8 62313 00115-150-00 3 • Link Bar, S3
9 61232 04011-001-01 12 • Hairpin Keeper
10 62007 04049-045-00 1 • Decal, Caution
11 62006 04049-044-00 1 • Decal, Danger
12 61196 04031-007-00 1 • Key, 1/4” Sq. x 1”
13 61156 04041-085-00 1 • Sprocket Drive 41 B 13
13b 61157 04041-086-00 1 • Sprocket Drive 41 B 19 (Old Style Hopper)
14 62358 04091-028-00 2 • Spring, Compression
15 62780 00115-165-00 1 • Hardware Bag
16 62331 00115-545-01 1 • Weld, R. H. Handle (Carbon Steel)
62781 00115-545-02 1 • Weld, R. H. Handle (304 Stainless Steel)
17 62782 00115-579-01 2 • Plate, Baffle (Carbon Steel)
62783 00115-579-02 2 • Plate, Baffle (304 Stainless Steel)
18 62333 00115-580-01 1 • Weld, L. H. Handle (Carbon Steel)
62784 00115-580-02 1 • Weld, L. H. Handle (304 Stainless Steel)
PARTS LIST FOR HYDRAULIC MOTOR DRIVEN UNITS
ITEM PART. NO. QTY. DESCRIPTION
----- 00002-296-15 1 Extended Hydraulic (Steel) Spinner Assy.
----- 00002-296-16 1 Extended Hydraulic (304SS) Spinner Assy.
----- 00119-092-01 1 • Weld, Spinner Frame (Carbon Steel)
----- 00119-092-02 1 • Weld, Spinner Frame (304 Stainless Steel)
62787 04101-119-00 1 • Motor, Hydraulic
----- 00119-085-00 1 • Weld, Shaft
62789 00115-722-01 1 • Bracket, Motor Mount (Carbon Steel)
62790 00115-722-02 1 • Bracket, Motor Mount (304 Stainless Steel)
62791 00107-080-00 2 • Bushing
62792 00107-080-01 2 • Bushing, (304 Stainless Steel)
PARTS LIST
00108-760-01-REV-B
Page 87
OCTOBER, 2013
