MFB SYNTH LITE II - MIDI Implementation; System Settings

MIDI Implementation
----------------------------------
Function Transmitted Recognized Remarks
Note ON 9nH, v = 1 -127 9nH, v = 1 - 127
Note OFF 9nH, v = 0 9nH, v = 0 or 8nH
Contr.Change
Mod.Wheel no 1 7 Bit
Interval 1 8 + 40 8 + 40 14 Bit
Interval 2 9 + 41 9 + 41 10 Bit
Rate 10 x 42 10 + 42 10 Bit
Level VCO1 11 11 7 Bit
Level VCO2 12 12 7 Bit
Level VCO3 13 13 7 Bit
Depth 14 + 46 14 + 46 12 Bit
Cutoff 15 + 47 15 + 47 14 Bit
Emphasis 16 16 7 Bit
Contour 17 + 49 17 + 49 12 Bit
Attack1 18 + 50 18 + 50 10 Bit
Decay1 19 + 51 19 + 51 10 Bit
Sustain1 20 + 52 20 + 52 10 Bit
Attack2 21 + 53 21 + 53 10 Bit
Decay2 22 + 54 22 + 54 10 Bit
Sustain2 23 + 55 23 + 55 10 Bit
Tune 24 + 56 no
Octave1 80 80 2 Bit
Wave1 81 81 2 Bit
Octave2 82 82 2 Bit
Wave2 83 83 2 Bit
Glide 84 84 2 Bit
Wave3 85 85 2 Bit
Program Change
User Memory00 - 83 00 - 83
Sequencer 84 – 103 84 - 103
System settings
There a few basic system settings for the SYNTH LITE II. Press and hold RECORD in
combination with the below listed buttons to edit:
Velocity
Octave (OSC1) 0 = Off 1 = VCF 2 = VCA 3 = VCF/VCA
MIDI Clock
Wave (OSC1) 0 = internal 1 = external
