MG LC User Manual

LC/LCS
EM-1355 Rev.6 P. 2 / 4
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
TERMINAL CONNECTIONS
Connect the unit as in the diagram below or refer to the connection diagram on the top of the unit.
■ EXTERNAL DIMENSIONS unit: mm (inch)
5678
21 1110
80 (3.15)
50 (1.97) 107 (4.21)
136 (5.35) [3.3 (.13)]
80 (3.15)
20
(.79)
40 (1.57)
50 (1.97)
7.8 (.31)
CLAMP
(top & bottom)
DIN RAIL
35mm wide
2 – 4.5 (.18) dia.
MTG HOLE
25 (.98) deep
11
– M3.5
SCREW
• When mounting, no extra space is needed between units.
39
4
■ CONNECTION DIAGRAM
7
8
+
–
–
10
3
9
6
11
+
STRAIN
GAUGE
2
1
INPUT
EXC.
+
–
OUTPUT
U(+)
V(–)
POWER

MG LC Specifications

General

Brand	MG
Model	LC
Category	Transmitter
Language	English
