MG MG800S - MG-Lock Measurement Mode (Scan MD) (No slope); Specifications; Key Specifications; Low Battery Alert & Replacing Battery

Specications
Low Battery Alert & Replacing Battery
When icon is seen in lower part of viewnder, 3V (CR2)
battery should be replaced. From the bottom of the device, simply
unscrew battery compartment cap, ensure that battery wrapper
has been removed, insert battery negative terminal rst (so positive
terminal remains visible after insertion) and replace cap.
• Slope Distance
Recommendation
• MG-Lock Finds Pins In
Front of Trees Etc...
• Vibrating MG-Lock
Conrmation
• 21mm Objective Lens
• 6x Magnication Power
• 7.2° View Angle
• ±5 Adjustable Diopters
(Glasses Unnecessary)
• Measurement in Yards
• Precision to +/- 1 Yard
• 3V Battery (CR2)
• IPX3 Water Resistance
Rating
• Range: 6 to 800+ Yards
• Dimensions:
3.03” x 1.58” x 4.13”
• Weight: 5.8 oz
MG-Lock Measurement Mode (Scan MD)
(No slope)
MG-Lock locks onto a agstick
with something (like a tree)
behind it. It is indicated by
the icon. Aim, then press
and release button.
Center target area will ash
briey while scanning and
then return distance of object
within it.
^
^
^
|
Scan
- - -
Y
Cart Magnets & Strap
Two powerful magents are embedded
in the right-hand side of the unit. These
can temporarily mount the device to
a ferrous metal surface like a golf cart.
(Please exercise caution before relying
on this feature to hold unit especially
when subjected to bumps, etc ... Not
recommended in situations where a drop
could be catastrophic.) A magnetic strap
is also included to ax device to non-
magnetic objects (such as a golf bag) as
well as to use as a hand-hold.
