TERMINAL CONNECTIONS
Connect the unit as in the diagram below.
■ EXTERNAL DIMENSIONS unit: mm (inch)
• ST
75 (2.95)9
(.35)
MOUNTING BRACKET
48 (1.89) sq.
approx. 20 (.79)
for wiring
MA
+–
0 20 10040 60 80
%
DOWNUP
11
0
• STL
80 (3.15)9
(.35)
MOUNTING BRACKET
24 (.95)
96 (3.87)
approx. 20 (.79)
for wiring
0
20
100
40
60
80
%
UP
DOWN
MA
STL
–
+
1
10
• Cable with connector
Approx. 1000 (3.3 ft)
* One end of the cable is cut off.
1
10
brown
red
yellow
green
purple
blue
orange
gray
white
black
■ CONNECTION DIAGRAM
UP
DOWN
MANUAL CONTROL
AUTO
1 brown (UP)
2 red (DOWN)
3 orange (COM.)
4 yellow
5 green
6 blue (+)
7 purple (–)
8 gray
9 white
10 black
AUTO-MANUAL
SELECTOR
SWITCH
OUTPUT
INDICATOR
MONITOR
TERMINALS
(4 – 20mA DC)
OUTPUT TO
BACKUP STATION
INPUT FROM
BACKUP STATION
+
–
