Wiring diagram
S 5P 000
Seite/page 3
Rakelarm Teil 1/
squeegee arm part 1
REV 1.0
07-0-0-0005-0
Kabel Rakel/
squeegeecable
schwarz/black
schwarz/black
blau/blue
braun/brown
B1 B2
front
rear
Kraftbrücke/
position sensors
20-0-0-0167-2
VornHinten
-
+
+
-
1 1
Magnetventil Rakel/
electromagnetic valve
squeegee
7
blau/blue
braun/brown
schwarz/black
weiss/white
CLEAN
X2
X3
A1J1
X5
S1
X6
X4
UNIT CONTROL Rev2
1
1
1
05-3-3-10101-0
A1
A2J4
BUS PCB
Seite/page 4
26
20-0-0-0555-3
GND
+24V
IN7
IN8
OUT8
OUT9
IN4
IN5
IN6
OUT5
OUT6
OUT7
all station switch off
on the first station switch on
Folientastatur Station/
keypad station
07-0-0-10002-0
red
black
black
red
