Installation instructions
Solix external roller blind
4. The frame is xed within the window frame via  AR xings.
Start with the two bottom ones and then tighten the top two AR xings.
Press
3
AR xing shown red by the
4
plastic grip (shown blue) up /
out into the corners and hold there
5
Tighten screws so they are hand-tight
Note: Make sure that the
3
AR xing has adeuate hold.
5. Close the window.
Note: If the window sash cannot be closed or can be closed only by force and it makes unusual noises, the Solix must be
taken out again and the specialist retailer contacted.
6. Reading the operating instructions
rior to rst use, it is imperative that you pay attention to the guidance in the operating instructions.
7. Taking down the Solix external roller blind
The external roller blind is taken down in reverse order to its installation.
First the external roller blind is retracted. Then, by undoing the four screws and pushing back the AR xings, the frame, complete
with the entire unit, can be taken out to the rear.
✔
✔
✘
3
3
3
4
5
3
3
Important information for the installer and user
