PART NO. DESCRIPTION BEVERAGE PACKAGE SHIPPING WEIGHT
MMDD4TAPV2
Dunkin' Donuts
®
Beverage Dispenser Dunkin' Donuts
®
Shuttle
385 kg
850 lbs
Condenser HP 1/6 HP
Ambient Temperature 45˚ - 100˚F
Inlet Water Temperature 45˚ - 90˚F
Inlet Water Pressure 30-50 psi
Charge 6.35 oz
Exterior
18 gauge 201 grade stainless steel (s/s) top, 22 gauge glass doors, 24 gauge steel front, sides and back. Front, sides, back
and doors black vinyl over steel.
Interior 20 gauge stainless steel oor and walls, rugged false oor, reinforced frame.
Ventilation Front breathing for cooling and exhaust.
Plumbing
Automatic condensate evaporator, no drain connection required. Evaporator condensate has been plumbed to a condensate
pan located in the compressor housing.
THIS EQUIPMENT IS TO BE INSTALLED WITH ADEQUATE BACKFLOW PROTECTION TO COMPLY WITH APPLICABLE
FEDERAL, STATE AND LOCAL CODES.
Insulation Foamed-in-place using high density, CFC-free polyurethane; 2" top, walls and oor.
Accessories Casters.
Shuttle Liquid Temp 40˚F Max, higher temps will result in insufcient gas infusion
Compressed Air System
Regulator Pressure
30 psi
Thermostat Set Point 33˚F
Running Amps 8.35A
Voltage 115/60/1
Plug Type NEMA-5-15P
Cord Length 8'
Refrigerant R-134a
OPERATING PERFORMANCE
SPECIFICATIONS
| 2
DUNKIN' DISPENSER INSTALLATION GUIDE AND SPECIFICATION SHEET
