Fig. 1
Fig. 2
Fig. 3
Disassemble of PremiumPLUS
Remove the lid [1].
Unscrew the bonnet by using the tool [5]
from the Service Kit.
PremiumPLUS
Service Kit - Part No. 122-170
Service Kit for PremiumPlus Reducer
www.micro-matic.com
1
5
2 1011 9 6 4 8 3 7
