Micro Mini2go Deluxe - Page 25

assemblInG the seat
25
EN
Mini2go Deluxe with
seat and storage com-
partment: ages 3 and up
Mini2go Deluxe with
handlebar: ages 2 and up
Mini2go Deluxe with
extended handlebar:
ages 3 and up
1. Make sure that the telescopic rod
12
is properly fastened to the Mini2go Deluxe and that the
red pin has locked into place in the opening on the main body of the scooter.
2. Place the seat
9
with the storage compartment
13
on the deck
6
and push the seat for-
wards until it is securely attached to the deck (see Fig. J).
3. Check to make sure that both barbed hooks on the seat housing have locked into place on the
underside of the deck.
4. Secure the seat housing by attaching the plastic covering
10
using the hexagonal bolt
11
(see Fig. K).
5. To remove the seat housing, follow steps 2 to 4 in reverse.
