Microair Avionics M760 Transceiver Installation & User Manual
760 install & user manual ver N Page 2 of 24 8
th
December 2003
About This Document
This manual describes the various installation configurations
available for the Microair M760 Transceiver. The
Transceiver’s controls and design features are described and
illustrated.
Microair reserves the right to amend this manual as required,
to reflect any enhancements or upgrades to the M760
Transceiver.
© Microair Avionics Pty Ltd
MICROAIR M760 ACCESSORIES
Wiring Harness
Boom Microphone
Speaker Box
Dynamic Microphone Amplifier
CURRENT REVISION STATUS
Revision Date Change
K 31/01/2000 Initial release
L 18/11/2001 Additional install data and wiring diagram added
M 04/10/2002 Additional wiring diagram added
N 08/12/03 Updated for revision N
