Getting started with Edison V3
5
Power saving mode
Please note: Edison V3 will turn off
automatically if not used after five
minutes however you can also power
down by pressing and holding the
square button for 3 seconds.
Left infrared LED
Right infrared LED
Left red LED
Right red LED
Left light sensor
Right light sensor
Infrared
receiver module
Processor
Left motor
Right motor
Serial number
and QR code
Keypad
Piezo transducer
(speaker/clap sensor)
Removable skid
Line tracking sensor
USB-A cable
Right wheel with
wheel encoder
Left wheel with
wheel encoder
EdCharger
charge contact
Rechargeable battery
(inside)
EdCharger
charge contact
