pDDL900 Operating Manual 9
A. Approved Antennas
This radio transmitter (IC: 3143A-17PDDL900) has been approved by ISED to operate with the antenna types listed
below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than
the maximum gain indicated for that type, are strictly prohibited for use with this device.
2400MHz antennas:
Group
Part Number
Description
Rubber Ducky
MHS031100
2dBi,2.4GHz Rubber Ducky Antenna RPTNC Swivel
MHS031110
2dBi, 2.4GHz Rubber Ducky Antenna Reverse SMA Swivel
MHS031120
2dBi, 2.4GHz Rubber Ducky Antenna Reverse SMA Straight
NW001
2.5dBi, Shenzhen Norminson Technology CO.LTD. - 2.4GHz
Rubber Ducky Antenna Reverse SMA Straight
WCP2400-MMCX4
2.5dBi, Laird Technologies - 2.4GHz Rubber Ducky MMCX
Yagi Antennas
MHS034100
9 dBi, 2.4GHz Yagi Directional Antenna RPTNC Pigtail
MHS034000
12 dBi, 2.4GHz Yagi Directional Antenna RPTNC Pigtail
MHS034120
14 dBi, 2.4GHz Yagi Directional Antenna RPTNC Pigtail
MHS034150
14.5 dBi, 2.4GHz Yagi Directional Antenna RPTNC Pigtail
Patch Antennas
MHS034200
8 dBi, 2.4GHz Mini Flat Patch Directional Antenna RPTNC Pigtail
MHS034210
14 dBi, 2.4GHz Flat Patch Directional Antenna RPTNC Pigtail
Omni Directional
MHS031260
5 dBi, Omni Directional Antenna RPTNC Pigtail
MHS034000
6 dBi, 2.4GHz Omni Directional Antenna RPTNC Pigtail
MHS031340
8 dBi, Omni Directional Antenna RPTNC Pigtail
MHS034020
10.5 dBi, 2.4GHz Omni Directional Antenna RPTNC Pigtail
MHS034030
12 dBi, 2.4GHz Omni Directional Antenna RPTNC Pigtail
MHS034040
15 dBi, 2.4GHz Omni Directional Antenna RPTNC Pigtail
