27
Radiated RF
IEC61000-4-3
(Test speci-
fications for
ENCLOSURE
PORT IMMUNITY
to RF wireless
communications
equipment)
Test
Frequen-
cy
(MHz)
Band a)
(MHz)
Service
a)
Modulation b) Modula-
tion b)
(W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
5240 5 100 –
5 800
WLAN
802.11
a/n
Pulse
modulation b)
217 Hz
0,2 0,3 9
5240
5785
NOTE If necessary to achieve the IMMUNITY TEST LEVEL, the distance between the transmitting antenna and the
ME EQUIPMENT or ME SYSTEM may be reduced to 1 m. The 1 m test distance is permitted by IEC 61000-4-3.
a) For some services, only the uplink frequencies are included.
b) The carrier shall be modulated using a 50 % duty cycle square wave signal.
c) As an alternative to FM modulation, 50 % pulse modulation at 18 Hz may be used because while it does not
represent actual modulation, it would be worst case.
The MANUFACTURER should consider reducing the minimum separation distance, based on
RISK MANAGEMENT and using higher IMMUNITY TEST LEVELS that are appropriate for the reduced minimum
separation distance. Minimum separation distances for higher IMMUNITY TEST LEVELS shall be calculated using
the following equation:
E=6/d √P
Where P is the maximum power in W, d is the minimum separation distance in m, and E is the
IMMUNITY TEST LEVEL in V/m.
