Rear Panel Output Card Locations
Each input/output card typically has four connectors with the port number identified as
shown in the figure below.
Port
1
Port 2 Port 3 Port 4
Port Locations for Input/Output Modules
See Appendix A of the SyncSystem 4380A Operations and Maintenance Manual for the
specifications of each card. For certain cards, the outputs can be configured via the 4380A
command interface. Further details are provided in the SyncSystem 4380A Software Users
Guide.
