60 Microsoft Broadband Networking Wireless Base Station User’s Guide
Technical Specifications
Base Station
Standards IEEE 802.11b, 802.11g, Wi-Fi certified, TCP/IP, NAT, DHCP, UDP,
FTP, PPPoE, PPTP, L2TP, HTTP, DNS, IPSec/VPN Pass through, WPA
Ports LAN:
O
Four 10/100 Mbps Switched Ethernet/IEEE 802.3 ports, Auto
MDI/MDI-X Crossover
O
RJ-45 Connectors
O
UTP/STP CAT 3 or better cabling required for 10 Base-T operation
O
UTP/STP CAT 5 or better required for 100 Base-TX operation
WAN:
O
One 10/100 Mbps Ethernet/IEEE 802.3 port, Auto MDI/MDI-X
Crossover
O
RJ-45 Connector
O
UTP/STP CAT 3 or better cabling required for 10 Base-T operation
O
UTP/STP CAT 5 or better required for 100 Base-TX operation
Data Rate 1, 2, 5.5, 6, 11, 12, 18, 24, 36, 48, 54 Mbps with Auto-fallback support
Modulation CCK, DBPSK, DQPSK, OFDM
Frequency Range ISM Band (2.400 to 2.4835 GHz)
Channels 1-11 United States, Canada
Approved for use only in the United States and Canada.
Wireless Security WEP: Off, 64-bit, and 128-bit
WPA: 256-bit
Indicators LAN (1-4): Link/Activity LED for each port
To Modem: Link/Activity LED
Wireless: Status LED including Activity indication
Power: Power/Reset Dual Color LED
Operating Temperature 0 to +40 deg C
Storage Temperature -20 to +60 deg C
Humidity 10 to 85 percent non-condensing
Emissions FCC Part 15 Class B; Canada RSS-210
Safety UL
Physical Dimensions 1.2" x 5.3" x 6.8" (30.5 X 134.6 X 172.7 mm)
Weight 10.97 oz (311 g) without power adapter
