8 9DIGITAL SNAKE DL32 Quick Start Guide
DIGITAL SNAKE DL32 Hook-up
Step 1: Hook-Up
DI Box
Keyboard
M15 M18B
M12
P16-D
Shielded CAT5
M32
iQ12
P16-M
DL32 rear panel connections DL32 common connections
Cabling for all AES50 connections between M32 and DL32 stageboxes:
• Shielded CAT-5e, Ethercon terminated ends
• Maximum cable length 100 meters (330 feet)
